Meats

The VACUCAM® Modular Solutions offer the total solution to meet all of your mix room needs —
both for today’s immediate challenges and tomorrow’s changing requirements and capacity demands.

The VACUCAM® Slurry Process is the most effective method for the complete dispersion of whey and milk proteins,
gelatin, pectins, gums, starch, sugar and all other dry ingredients typically used in the manufacture of meat products.

MEATS

MEATS

The VACUCAM® Ejector Mixer offers several high capacity processes for efficiently making all of the Pickle Room mixes and Spice Mix additions to your process on a semi-automated or totally automated basis.

Improved powder liquid mixing for batch to batch consistency.

New food introductions require additional process requirements:

  • To handle changing ingredients that cannot be mixed efficiently with traditional mix stations or mixing technology.
  • To handle bulk bag addition of ingredients as well as small packages for dry and liquid minors.
  • To handle the changing needs for sweeteners and addition of totally new ingredients.

Modular Design

Expand your process capabilities for a TOTAL mix process.

  • Meet growing and changing demands w/modular additions to existing system.
  • Build TOTAL sustainable process for ALL mix requirements.
  • Meet 3A/USDA specifications
  • Accommodate dry feed from paper bag, drums, bulk bag or bulk.
  • Achieves CIP compatibility of all components on both the dry and the wet sides of the process.

Features

  • Complete dynamic dispersion
    • Easily mixes multiple ingredients
  • Isolates dry ingredients representing allergic or other cross-contamination issues.
  • Maximizes powder incorporation rates
  • Full CIP capability
  • Multi-functional design allows for maximum utilization.
  • Sugar-on-demand – eliminates need for sucrose syrup storage. Delivers batch quantity directly into blend tank.
  • Sugar – high capacity, using Semi-Bulk Systems unique powder handling / sugar liquefication processes.
  • Cocoa – Integrates into UHT process with complete dispersion and controlled amount of shear on cocoa.
  • Functionalize gums & stabilizers without sheer
  • Meets 3A/USDA standards
  • Accommodates smaller footprint – simplified unit operations
  • Clean, dust-free operation – no dust collection on batch tank
  • Total Automation – Integrates Batch Menu Controls.
  • Improves Operator Safety & GMP
    • Eliminates high frequency injuries with ergonomic process design
    • Floor level operation
    • Eliminates operator platforms
  • Reduces manual handling by moving from small bag to bulk bag capability

Benefits

CAPACITY

  • High capacity rates – can feed several lines with minimum batch cycle times
  • Minimum batch times
  • Increase product yields

QUALITY

  • Batch to batch consistency
  • Improved overall mix quality.
  • Maximized efficiency of the UHT process.
  • No fisheyes/agglomerates

OPERABILITY

  • Allows for parallel processing – eliminates sequential batching for functional ingredients, sweeteners, cocoa, and sugar.
  • Low / No maintenance – Pump is only moving part.
  • Low energy consumption
  • Low labor requirements

The Total Solution for Meat Slurries

The TOTAL SOLUTION for making Meats is provided in standardized modular skids to address mix processes and with total design dry handling systems to address dry bulk ingredients, bulk bags, paper bags or minor ingredients.

TYPICAL INGREDIENTS/MIXES

  • Aspartame
  • Caffeine
  • Citric Acid
  • Crystallized Fructose
  • Erythritol
  • Filter Aids
  • Formulations Requiring Emulsions
  • Maltodextrin
  • Non-Fat Dry Milk (NDFM)
  • Pectins, Gums, Thickeners
  • Potassium Benzoate
  • Sodium Citrate
  • Sucrose
  • Tea Powders
  • Thickeners (Gums, Pectin & Starch)

Mixer On A Tank

Mixer On A Stand for Thickeners

VACUCAM® Technology

Semi-Bulk Systems can design and integrate the Vacucam® in-line system to feed finished slurry into multiple locations of your preference, such as storage or mix tanks.

Air-Cone® Hopper

The Air-Cone® Hopper’s ability to condition difficult powders makes it ideal for applications where dependable flow and total discharge are critical.

VACUCAM® Ejector Mixer

Semi-Bulk Systems VACUCAM® Ejector Mixer Dynamic Batching Station provides the most efficient dispersion, mixing and hydration of ALL dry ingredients used in today’s broad range of product types and ALL processes.

The Vacucam® Ejector Mixer is the most effective system available for conveying, wetting, and dispersing powders into liquids.

Here is how it works.

Conditioned powder is conveyed into the mixer by a near-perfect vacuum, which is created when pressurized fluid is discharged as a high-velocity, hollow jet into which the powder is drawn.

The high speed dispersion mixer.

The Vacucam® system achieves high-speed, instantaneous and complete wetting by bringing together conditioned powder and highly atomized liquid from two separate streams, incorporating particles of liquid with particles of powder. The reactive surface areas of both the powder and the liquid are maximized before intimate contact is actually made. The result is consistently uniform, superior wetting without the agglomeration or “clumping” usually associated with conventional mixing methods.

Semi-Bulk Systems can design and integrate the Vacucam® in-line system to feed finished slurry into multiple locations of your preference, such as storage or mix tanks. Your entire process can be physically separated and centrally controlled. Semi-Bulk Systems provides options such as mounting the Ejector-Mixer on your tanks or integrating our system with your existing process.

The best fluid ejector upgrade with improved efficiency over the traditional fluid mixer.

Since the Vacucam® system achieves high-speed, instantaneous and complete mixing, it makes it perfect for fluid mixing too. You can bring together highly atomized liquids from two separate streams for batch to batch consistency and uniform mixing.

Air-Cone® Hopper

The Air-Cone® Hopper’s ability to condition difficult powders makes it ideal for applications where dependable flow and total discharge are critical. Batch-to-batch variations due to material hold-back are virtually eliminated when it is used as a weigh hopper.

Since the conditioned powder is able to flow freely, the Air-Cone® Hopper is an excellent feed source for vacuum conveyors and for the VACUCAM® Ejector Mixer above.

Here’s how the system works

An inner membrane completely covers the surface where product comes into contact with the cone. Low pressure “conditioning” air or inert gas is distributed by an air supply manifold and diffused through the membrane wall. When the dry ingredients are conditioned, they assume the properties of a liquid and can then flow smoothly and accurately into your manufacturing process. This aeration process eliminates some of the typical production problems with difficult powders such as bridging and rat holes.

Total Dry Mix Automated Process

  • Single In-Line process to deliver to selected mix tanks
  • Separate dry room from wet area
  • Bulk bag handling of major ingredients, paper bag handling of minor ingredients
  • Multiple bulk bag hoppers for automated powder delivery of all dry ingredients

Dry Side Delivery

  • Paper Bags
  • Bulk Bags
  • Bulk Truck
  • Bulk Rail
  • Bulk Silo

FAQs

Automated Dry Ingredient Handling in Meat Processing Plants offers many benefits for Process XstreamLiningsm to allow Meat Processors the opportunity  to improve plant efficiencies and maintain or develop Market Advantage in the 21st Century.  Semi-Bulk Systems offers complete packaged processes to automate your Pickle Mix room or your Spice Mix operation with the VACUCAM® Ejector Mixer Technology.  Automated Systems are available to rapidly provide dependable, repeatable and controllable brine solutions to your processes.  The technology has gained rapid acceptance in Food/Dairy Processing plants, Beverage manufacture and Neutraceuticals meeting all appropriate designs for sanitation and cleaning for both the dry side and wet side processing.

The VACUCAM® Ejector Mixer offers several high capacity processes for efficiently making all of the Pickle Room mixes and Spice Mix additions to your process on a semi-automated or totally automated basis.  The PLC controls will store all of your recipes and will automatically make your batch of Pickle mix and pump to the appropriate Pickle feed tank.  The controls will provide consistency and validate each and every batch of Mix made.

Pickle Mix Solutions

Pickle Mix solutions are automatically processed based on a level signal in the appropriate feed tank.  Dry Ingredients are pre staged with the minor ingredients supplied from surge hoppers with feeders.  The higher volume ingredients are conveyed to the Vacucam Ejector Mixer directly from bulk bag unload/surge hoppers or bag dump surge hoppers with load cells.

The Vacucam® Ejector is mounted on a batch mix tank.  The controls will automate the addition of batch water and liquid additions and then sequentially convey and mix the precise batch quantities of minor ingredients, salt and sugar for a rapid and total mix .  After all of the batch liquid additions and dry ingredients are mixed in the batch tank, the controls will automatically switch the proper transfer valve to the proper pickle feed tank and pump the mix to that tank.  The system is now available for the next automated batch selection.  The PLC controls will allow ready access to management to monitor plant operations.  Printed reports can document and validate daily production.

Spice Mix Making

Spice and liquid additions to meat mixers are generally very inefficient, labor intensive and ergonomically and environmentally deficient.  The VACUCAM® Automated Slurry Process addresses rapid and efficient handling and incorporation of dry spice ingredients as well as water and liquid additions.

The Vacucam® Ejector is mounted on a batch mix tank.  The controls will automate the addition of batch water and liquid additions and then sequentially convey and mix the precise batch quantities of spices and other minor ingredients, salt, starches, etc. for a rapid and total mix.  Systems can accommodate spice blends or individual spices.   After all of the batch liquid additions and dry ingredients are mixed in the batch tank, the controls will automatically switch the proper transfer valve to the proper meat mixer and pump the mix through a header pipe to rapidly and uniformly distribute in the meat mix.  The system is now available for the next automated batch selection.  The PLC controls will allow ready access to management to monitor plant operations.  Printed reports can document and validate daily production.

Brine Mix Making

Processes are available to improve the handling of salt and to repeatably deliver known and validated Brine concentrations to your processes.

Systems described above can handle bulk bags of salt and rapidly and efficiently incorporate the proper brine levels into Pickle or Spice Batch Mixes without using prepared brine solutions of questionable concentrations.

Systems are also available to receive and rapidly dissolve salt from bulk truck deliveries to store known brine solutions in large tanks or silos.  Concentrations can be controlled and validated to assure accuracy of salt additions.
